WEIGHT (CARD)	169g
Efficiency Rating	80 PLUS Gold (up to 90%)
Dimensions	120mm x 120mm x 25.6mm
Modular	Yes (full modular)
Fan Bearing	Fluid Dynamic Bearing
Bearing Type	Hydro-Dynamic Bearing
Rated Speed	500 - 1800 ±15% RPM
Power Watt	850W
Power Excursion	1700W (*up to 200% of the PSU's rated power for 100μs)
Input Voltage	100~240 VAC
Air Flow	19.79 - 71.27 CFM
Static Air Pressure	0.16 - 2.09 mm-H20
Input Frequency	47-63Hz
Connector	4-Pin PWM/DC
ATX (24 pin)	1
Life Expectancy	MTTF 150,000 Hours (25℃)
EPS (4+4 PIN)	2
Fan Size	120 mm
PCI-E 5.0 (16 pin)	1 (600W)
Dimensions (DxWxH)	140 x 150 x 86 mm
PCI-E (6+2 pin)	4
PFC Type	Active PFC
SATA (15 pin)	8
Protection	OCP / OVP / OPP / OTP / SCP / UVP
MOLEX (4 pin)	4
FDD (4 pin)	1

","image":["/images/msitech.shop/images/product/msi-cb-desktop-pc-netzteil-atx-850watt-80-plus-gold-mag-a850gl-pcie5-1.png","/images/msitech.shop/images/product/msi-cb-desktop-pc-netzteil-atx-850watt-80-plus-gold-mag-a850gl-pcie5-2.png","/images/msitech.shop/images/product/msi-cb-desktop-pc-netzteil-atx-850watt-80-plus-gold-mag-a850gl-pcie5-3.png","/images/msitech.shop/images/product/msi-cb-desktop-pc-netzteil-atx-850watt-80-plus-gold-mag-a850gl-pcie5-4.png","/images/msitech.shop/images/product/msi-cb-desktop-pc-netzteil-atx-850watt-80-plus-gold-mag-a850gl-pcie5-5.png","/images/msitech.shop/images/product/msi-cb-desktop-pc-netzteil-atx-850watt-80-plus-gold-mag-a850gl-pcie5-6.png","/images/msitech.shop/images/product/msi-cb-desktop-pc-netzteil-atx-850watt-80-plus-gold-mag-a850gl-pcie5-7.png","/images/msitech.shop/images/product/msi-cb-desktop-pc-netzteil-atx-850watt-80-plus-gold-mag-a850gl-pcie5-8.png"],"sku":"msi-cb-desktop-pc-netzteil-atx-850watt-80-plus-gold-mag-a850gl-pcie5","brand":{"@type":"Brand","name":"MSI e-Shop"},"offers":{"@type":"AggregateOffer","lowPrice":44.92,"highPrice":44.92,"priceCurrency":"USD","availability":"https://schema.org/InStock","url":"https://msitech.shop/products/msi-cb-desktop-pc-netzteil-atx-850watt-80-plus-gold-mag-a850gl-pcie5","offerCount":1}}

Home Shop

MSI CB Desktop PC Netzteil ATX 850Watt 80 Plus Gold MAG A850GL PCIE5

$44.92

Original: $128.35

-65%

MSI CB Desktop PC Netzteil ATX 850Watt 80 Plus Gold MAG A850GL PCIE5—

$128.35

$44.92

Original: $128.35

-65%

MSI CB Desktop PC Netzteil ATX 850Watt 80 Plus Gold MAG A850GL PCIE5—

$128.35

$44.92

Die Geschichte

MAG A850GL PCIE5

ATX 3.1 kompatibel, nativer PCIe 5.1 Anschluss
Unterstützt Grafikkarten der NVIDIA^® GeForce RTX^™ 40 Serie
Vollständig modulares Design, flache Kabel
80 Plus Gold Zertifizierung für hohe Effizienz
Aktives PFC-Design, industrieller Schutz mit OVP, OCP, OPP, OTP, SCP, UVP
120mm Lüfter mit dynamischen Kugellager
LLC-Vollbrückentopologie mit DC-DC-Modulentwurf

WEIGHT (CARD)	169g
Efficiency Rating	80 PLUS Gold (up to 90%)
Dimensions	120mm x 120mm x 25.6mm
Modular	Yes (full modular)
Fan Bearing	Fluid Dynamic Bearing
Bearing Type	Hydro-Dynamic Bearing
Rated Speed	500 - 1800 ±15% RPM
Power Watt	850W
Power Excursion	1700W (*up to 200% of the PSU's rated power for 100μs)
Input Voltage	100~240 VAC
Air Flow	19.79 - 71.27 CFM
Static Air Pressure	0.16 - 2.09 mm-H20
Input Frequency	47-63Hz
Connector	4-Pin PWM/DC
ATX (24 pin)	1
Life Expectancy	MTTF 150,000 Hours (25℃)
EPS (4+4 PIN)	2
Fan Size	120 mm
PCI-E 5.0 (16 pin)	1 (600W)
Dimensions (DxWxH)	140 x 150 x 86 mm
PCI-E (6+2 pin)	4
PFC Type	Active PFC
SATA (15 pin)	8
Protection	OCP / OVP / OPP / OTP / SCP / UVP
MOLEX (4 pin)	4
FDD (4 pin)	1
